4GB USB NAND Tool for Xbox 360 Corona

4GB USB NAND Tool for Xbox 360 Corona Motherboards

The 4GB USB Tool, designed by Element of The Mod Shop, provides a simple and reliable way to read and write the NAND on Xbox 360 Corona motherboards fitted with 4GB NAND storage.

Instead of having to find a compatible external SD card reader capable of detecting the Corona NAND, the required reader functionality is built directly into the tool. This makes the process considerably easier and provides compatibility with 4GB NAND variant Corona motherboards.

Easy Connection for Installers

Unlike the earlier SD Tool V2.2, where only the crystal connection needed to be disconnected, this tool requires the connection to be completely removed before the console can boot after writing an ECC file or XeBuild image to the NAND.

To make repeated connection and removal easier, the tool is supplied with a dedicated connectivity kit.

A pin header is soldered to the Xbox 360 motherboard, allowing the supplied IDC connector to be quickly connected or disconnected when required. A second pin header is fitted to the USB tool for connection to the Dupont connector on the opposite end of the cable.

The crystal connection wire is supplied open-ended and must be soldered or desoldered as required during the installation process.

Ideal for Console Modders and Installers

Replacement right-angle motherboard pin headers are also available separately, making the tool particularly useful for professional or high-volume installers working on multiple consoles.

Available in the UK and Europe exclusively from ChipChopMod.

Package Contents

• 1 × 4GB USB Tool
• 1 × USB Tool Cable
• 1 × Motherboard Pin Header
• 1 × USB Tool Pin Header

Important: Installation requires soldering and is intended for users experienced with Xbox 360 motherboard modification and NAND programming.
